25 mm, 4K, M42-mount Line Scan Lens (LS-LSB2530A)
Model LS-LSB2530A
25 mm, 4K, M42-mount Line Scan Lens. 4K Line Scan Lens.
Features
- Large image format Φ29mm
- Uniform imaging
- Shock-resistant focusing locking mechanism
Specifications
| Model | LSB2530A |
|---|---|
| Focal length (mm) | 25 |
| Image circle (mm) | 29 |
| Resolution (um) | 4K7µm |
| Iris (F/#) | 3.0-16 |
| Magnification range (X) | 0.086-0.275 |
| Filter screw size | M30.5 * P0.5 |
| Mount | M42/M58 |
| Shipping weight (estimated) | 0.70 kg |
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
Light controllers LensesSelection guideOther sizes in the 4K line scan lens (LSB, image circle 29 mm) series
| Model | Size | Power | Colours | Price | |
|---|---|---|---|---|---|
| LS-LSB204K | 20 mm, 4K, M42-mount | $369.00 | View | ||
| LS-LSB354K | 35 mm, 4K, M42-mount | $399.00 | View | ||
| LS-LSB504K | 50 mm, 4K, M42-mount | $419.00 | View |
